Tick a checkbox on the morning brief, and by the next morning the task has moved to the archive. Draw an arrow after a task and write soon, and it drops off page 1. Write a sentence beside a task, and the sentence appears in the task's file under a dated heading.

This post builds that return path, from pen strokes on the reMarkable to edits in the vault from part 1. It reads the briefs that part 2 delivers, and it runs at the start of the same 05:00 job. The code is at github.com/morganp/rmocr.

What comes back from the tablet

rmapi get downloads a document from rmfakecloud as an .rmdoc file, which is a zip archive:

<doc-id>.pdf              the original brief, byte for byte
<doc-id>.content          page order and document settings
<doc-id>/<page-id>.rm     the ink for one page, version 6 format

A PDF-backed document stores the pen strokes in a separate layer from the PDF. Each .rm file holds only the ink, and only pages with ink have one, so there is no need to compare the page against the original render. The rmscene library parses the version 6 format into strokes, and each stroke is a list of points:

def rm_strokes(path):
    out = []
    with open(path, "rb") as f:
        for b in read_blocks(f):
            if isinstance(b, SceneLineItemBlock):
                line = getattr(getattr(b, "item", None), "value", None)
                if line is not None and getattr(line, "points", None):
                    out.append([(p.x, p.y) for p in line.points])
    return out

PyMuPDF reads the PDF side: the page size, the text lines with their positions, and the drawing commands.

A vocabulary of ink

Four marks carry meaning on a task row. Everything else is a note:

The arrow turns a word into an instruction. work written beside a row without an arrow is a note; → work moves the action to the work area. The instruction words form a fixed list:

A bare weekday means its next occurrence, never today, and next Friday means the Friday after that. A few aliases map to the list, such as someday to sometime and blocked to waiting. Any other word is reported and never applied, so a misread instruction cannot demote a task.

Calibrating pen to page

The strokes and the PDF use different coordinate systems. A calibration sheet maps one to the other. The sheet is a blank page at the brief's size, 509 by 679 points, with five crosshairs at known positions. calibration_sheet.py draws it:

from reportlab.pdfgen import canvas

W, H = 509, 679
TARGETS = [("CIRCLE", 100, 100), ("TRIANGLE", 409, 100),
           ("SQUARE", 100, 579), ("HEXAGON", 409, 579),
           ("CROSS", 254.5, 339.5)]

c = canvas.Canvas("calibration.pdf", pagesize=(W, H))
for name, x, y in TARGETS:
    y = H - y                     # targets are top-left origin
    c.line(x - 10, y, x + 10, y)
    c.line(x, y - 10, x, y + 10)
    c.drawString(x + 14, y + 4, name)
c.save()

To calibrate a tablet:

1. Run calibration_sheet.py --out calibration.pdf, and push the sheet to the tablet with rmapi put calibration.pdf.
2. Draw the named shape centred on each crosshair, with the pen you use for the brief.
3. Fetch the document with rmapi get, and unzip it.
4. Run fit.py <folder> --json-out transform.json, and set RM_TRANSFORM to that file.

fit.py groups the strokes into five shapes and takes the centre of each. It then solves a least-squares fit for a full affine transform, one equation per axis:

x_pdf = 0.31456127 x + 0.00032105 y + 253.1235
y_pdf = 0.00028972 x + 0.31615912 y +   1.3471

A full affine fit allows for a different scale on each axis, a small rotation and an offset. On a Paper Pro the two scales differ by about 0.5%, and the corner residuals come out below 0.5 points. Put the six coefficients in transform.py, or leave them in the JSON file named by RM_TRANSFORM. Every later step passes each stroke point through to_pdf().

overlay.py draws the transformed strokes in blue over the page, with the checkboxes outlined in red. Run it on the calibration sheet and on the first real brief: each tick should sit inside its box.

Assigning ink to rows

The brief draws each checkbox as a 7 by 7 point stroked rectangle, as described in part 2. rmocr finds them in the page's drawing commands, not in the image:

def checkbox_rects(page):
    """7x7 stroked squares from the content stream, in top-left origin space."""
    rx = re.compile(rb"(-?[\d.]+)\s+(-?[\d.]+)\s+(-?[\d.]+)\s+(-?[\d.]+)\s+re")
    H = page.rect.height
    out = []
    for m in rx.finditer(page.read_contents()):
        x, y, w, h = (float(g) for g in m.groups())
        if abs(w - BOX_SIZE) < BOX_TOL and abs(h - BOX_SIZE) < BOX_TOL:
            out.append([x, H - y - h, x + w, H - y])   # -> top-left origin
    return sorted(out, key=lambda r: (r[1], r[0]))

Each checkbox defines a row band, from the top of its box to the top of the next box. The strokes then pass through three tests, in order:

• Tick: at least 4 points of ink length inside the box, padded by 2.5 points. The test measures ink length rather than a single hit, so a stroke that only crosses the box does not count.
• Strike: a stroke at least 25 points wide and at least four times wider than it is tall, lying across a line of printed text.
• Note: everything else. Strokes group into clusters within one row band when they are less than 26 points apart.

A note cluster attaches to a row when at least a quarter of its height overlaps the row band, and when it spans no more than two rows. Vertical overlap decides, not distance, so a note in the far margin still reaches its task. A note that spans more rows is a free note, and it is reported rather than written anywhere.

The row title is the printed text beside the box, including the second line of a wrapped title. It must match the # heading of exactly one action file. A title with no match, or with two, is reported and skipped, because a wrong match would archive the wrong task.

Reading the words

Each note cluster becomes a small image of black strokes on white. The crop follows the cluster with a 12 point margin. The strokes render at 4 pixels per point with the pen width of the Fineliner, and the printed page stays out of the image.

The Claude Code CLI transcribes the image. The prompt gives the image path and the printed row as context, and the only tool allowed is Read:

cmd = [CLAUDE_BIN, "-p", prompt, "--allowedTools", "Read"]
p = subprocess.run(cmd, capture_output=True, text=True, timeout=timeout,
                   env=env, cwd=os.path.dirname(img_path))

For a note beside a task row, the prompt asks for one JSON object:

{"gesture": "arrow", "text": "soon"}

The model decides whether an arrow is present, because a small, fast arrowhead is easier to name than to measure. The prompt tells it to answer none unless it can see an arrowhead. The text then goes through the instruction parser when gesture is arrow, and becomes a note otherwise.

Applying edits

writeback.py turns the results into an edit plan and prints it. By default it changes nothing. For the page above, the plan reads:

PLANNED EDITS (3)
  p1  archive renew-car-insurance (checkbox ticked)
  p1  set stage = soon on service-the-lawnmower (arrow + priority, raw 'soon')
  p1  archive submit-expenses-q3 (checkbox ticked)

With --apply it edits the action files, moves archived actions into archive/actions/, and commits the result to the vault. It refuses to run on a vault with uncommitted changes, so a writeback commit only ever holds writeback edits.

A ledger in state/applied.json records each applied edit. The key is a hash of the document, page, action, operation and content:

def key(doc_id, edit):
    a = edit["action"]
    raw = "|".join([doc_id, str(edit.get("page", "")), edit["op"],
                    a.get("id", ""), _payload(edit)])
    return hashlib.sha256(raw.encode("utf-8")).hexdigest()[:20]

Reading the same ink twice finds the key and skips the edit. A different note beside the same row on a later brief has a new key and applies. The next brief then lists the applied edits, and anything that needs attention, on its "Written back from paper" page.

Wiring it into the 05:00 run

The writeback runs at the top of generate_daily_brief.sh, before the brief renders, so today's brief already reflects yesterday's ink. It processes the last four briefs, because the tablet may not have synced overnight; the ledger makes each repeat free. For each brief, the script:

1. Fetches Daily/<date> brief with rmapi -ni get, and skips the day if there is none.
2. Unzips it, and skips it if there are no .rm files.
3. Runs writeback.py --apply, and continues to the next brief if it fails.
4. Pushes the vault once, if any brief produced a commit.

No failure in this stage stops the brief. A missing rmocr install, a vault with uncommitted changes, or a failed transcription each log a line and move on.

To set it up, clone the repository to /opt/rmocr and create its virtual environment:

python3 -m venv .venv
./.venv/bin/pip install -r requirements.txt

Then calibrate your tablet, and run writeback.py without --apply on a brief you have written on. When the plan matches your ink, the 05:00 job applies the next one.
